TDR and FDR soil moisture sensors with soil-type-specific calibration functions achieving sub-3% VWC accuracy in clay, sandy loam, and organic soils; ISOBUS TC-GEO task controllers at AEF certification level with section control boundary error below 25cm at 8km/h; multi-constellation RTK GNSS electronics achieving sub-2cm accuracy from L-band correction services; livestock GPS and accelerometer ear tag electronics with edge ML oestrus classification at 3× baseline activity threshold; and LoRaWAN soil monitoring nodes validated for 4.8-year primary battery life at 52°N.
The Engineering Problem
Precision Agriculture Electronics Fails at the Soil Physics, the ISOBUS Timing Budget, the Battery Energy Balance, or the Platform Data Model — Often All Four Simultaneously
A soil moisture sensor in a clay loam calibrated with the manufacturer's generic mineral soil equation produces VWC readings 6-8% higher than actual, because clay mineral surface water contributes to TDR-measured dielectric permittivity without contributing to plant-available water — and an irrigation controller acting on these readings applies 20-25% more water than the crop needs. An ISOBUS task controller without TC-GEO section control cannot use GPS position to activate individual boom sections at field boundary edges, wasting 8-15% of applied agrochemicals in every pass. A solar-powered soil node designed for summer insolation with no winter energy balance calculation stops transmitting in January in a Scottish arable field — precisely when drainage management decisions need it. A farm sensor delivering proprietary binary data in a format the FMIS cannot ingest without a custom parser sits in the field generating data the agronomist cannot see.
John Deere Operations Centre, Trimble Ag, Climate FieldView, and AgriWebb are transitioning from data repositories to agronomic decision engines — creating demand for sensor and machine electronics that produce data in the formats these platforms ingest, at the accuracy levels their recommendation algorithms require. Agricultural carbon markets, biodiversity net gain programmes, and sustainable farming incentive schemes require continuous field-level measurement of soil carbon, biology, and water balance — creating demand for novel agricultural sensor electronics designed for the soil health variables that determine carbon credit issuance and biodiversity payment verification. Autonomous weeding robots, harvest robots, and unmanned aerial application systems moving from demonstration to commercial operation are demanding centimetre-accuracy positioning and real-time machine intelligence at the agricultural cost point that farm economics can support.
We design precision agriculture electronics from the agronomic decision requirement outward — the specific crop management decision the system must support, the measurement accuracy and data resolution needed to make that decision confidently, the sensing technology appropriate for the measurement environment, and the connectivity and power architecture that delivers measurement data reliably across farm scale and multi-season deployment. Precision agriculture technology companies, agricultural equipment manufacturers, irrigation management vendors, crop protection companies, livestock management companies, agricultural drone companies, soil health vendors, and greenhouse technology companies all need this engineering depth.
Smart Agriculture & Precision Farming Electronics Categories We Build
From multi-depth TDR soil moisture networks with soil-specific Topp equation calibration to ISOBUS TC-GEO task controllers to livestock GPS oestrus detection to greenhouse VPD climate management — every farming application domain, every crop type, every precision measurement challenge.
Precision Soil & Irrigation Monitoring Networks
ISOBUS Precision Application & Variable Rate Machine Electronics
Livestock Health, Behaviour & Traceability Electronics
Greenhouse & Controlled Environment Agriculture Electronics
Crop Remote Sensing & Agricultural Drone Payload Electronics
GNSS Guidance, Auto-Steer & Field Mapping Electronics
Farm Weather Station & In-Canopy Microclimate Monitoring
Farm Data Gateway, IoT Connectivity & FMIS Integration
Soil Sensing & Calibration Physics
TDR propagation velocity measurement and Topp et al. (1980) equation for volumetric water content from bulk dielectric permittivity, with soil-type-specific calibration for clay, loam, and organic soils where the generic mineral soil equation introduces 4-8% VWC error from clay surface water and organic matter dielectric contribution. FDR capacitance measurement with excitation frequency optimisation for reduced salinity sensitivity; tensiometer pressure transducer signal conditioning for matric potential; EM38/EM31 electromagnetic induction for apparent EC soil survey and management zone delineation; multi-depth sensor multiplexing to 90cm for root zone profiling.
ISOBUS & Agricultural Machine Integration
ISO 11783 ISOBUS physical and data link layer design for tractor and implement integration; Task Controller device implementation at AEF levels TC-BAS, TC-GEO, and TC-SC; Virtual Terminal client firmware for standard tractor display; section control activation from GPS position for 8-15% input savings at headlands and field corners; ISOBUS XML task file import and export for FMIS prescription and regulatory documentation; individual nozzle PWM at 100-120Hz; ISOBUS TECU interface for machine speed, PTO, and hitch position. AEF interoperability test suite awareness drives TC implementation.
Precision GNSS & Variable Rate
Multi-constellation GNSS RTK electronics achieving sub-2cm horizontal accuracy from NTRIP or L-band satellite correction (Trimble RTX, Hemisphere Atlas, OmniSTAR HP); dual-antenna GNSS for machine heading and implement pitch; GNSS dead reckoning from IMU and wheel pulse for positioning continuity under canopy; prescription map position look-up firmware correlating GPS position with variable rate zone for real-time rate setpoint; variable rate zone transitions within 1-3 seconds; speed-based application rate control maintaining target rate as machine speed varies.
Livestock Telemetry & Biometrics
Multi-axis accelerometer and gyroscope signal conditioning for livestock behaviour classification covering oestrus, rumination, lying, calving, and disease precursor detection; oestrus firmware detecting 3× baseline activity surge within a 20-minute window with configurable false positive management; GPS tracking with solar-assisted multi-week battery life; EID ISO 11784/11785 134.2kHz transponder reader for individual animal identification at handling points; rumen bolus temperature and pH monitoring for ketosis and acidosis; edge ML behaviour classification on ARM Cortex-M4 for real-time alerts without cloud round-trip.
Greenhouse & CEA Electronics
Temperature, humidity, and CO2 monitoring for multi-zone greenhouse climate management with aspirated radiation shield; VPD calculation firmware from temperature and RH for stomatal conductance management in high-value crops; PAR and DLI monitoring from quantum sensor interface for lighting management; nutrient solution EC, pH, DO, and temperature monitoring for hydroponic and NFT systems; grow light PWM dimming for spectrum and photoperiod control; energy sub-metering for heating and lighting efficiency; vertical farm rack sensor array electronics for multi-tier climate uniformity monitoring.
Farm Connectivity & Power Architecture
LoRaWAN gateway electronics achieving 15-20km rural coverage from barn or grain store elevation for farm-wide sensor networks from a single gateway; solar MPPT validated at deployment latitude winter insolation minimum — not summer peak — for reliable year-round operation; primary Li-SOCl2 battery characterised at low temperature for cold-climate deployment; adaptive sampling firmware balancing data frequency with seasonal energy variation; LTE-M and NB-IoT where LoRaWAN infrastructure is absent; Iridium SBD for ultra-remote rangeland monitoring; ultra-low-power livestock ear tag firmware achieving 2-3 year battery life at daily GNSS and activity transmission.
Agronomic Data Management
ISOBUS XML task file (ISO 11783-10) prescription import from FMIS variable rate recommendation; ADAPT data model compliance for cross-platform data exchange; GeoJSON and ESRI Shapefile field boundary and zone map management for GIS-referenced agronomic records; FMIS API integration with John Deere Operations Centre, Climate FieldView, Trimble Ag, AgriWebb, and Herdwatch for automated data delivery in platform-native format; application record generation in ISOBUS XML for regulatory compliance; yield map data processing from combine harvester mass flow and moisture data with position correlation; ring buffer management for field connectivity outage continuity.
Crop & Environmental Sensing
NDVI and NDRE reflectance sensor electronics from multi-spectral LED and photodetector arrays for crop nitrogen and biomass monitoring; chlorophyll fluorescence interface for photosynthetic stress detection; leaf wetness sensor electronics with temperature correlation for spray timing and infection risk period management; pyranometer and net radiometer signal conditioning for solar radiation and energy balance; Penman-Monteith ET0 firmware from FAO formulation for irrigation scheduling; acoustic and optical crop height monitoring; pheromone trap camera and insect count interface electronics for integrated pest management.
Chipsets & Platforms
Platforms, ICs & Standards
Tested silicon and proven stacks — no experimental platform dependencies.
Precision Soil, Irrigation & Crop Monitoring Electronics
TDR Soil-Specific Calibration. Multi-Depth Root Zone Profiling. ET₀ Penman-Monteith. Leaf Wetness. Deficit Irrigation Control. FMIS Integration.
Controlled deficit irrigation trials consistently demonstrate 30-40% water reduction at equivalent yields — but only when soil moisture data is accurate enough for an irrigation controller to schedule from soil water status rather than calendar. The three-phase dielectric mixing model predicts that clay mineral surface water and organic matter dielectric properties distort generic Topp equation readings by 4-8% VWC, making soil-type-specific calibration the foundation of any agronomically useful TDR measurement. Ankh engineers TDR soil moisture electronics with soil-specific calibration verified by gravimetric sampling at each site, multi-depth profiling at 10cm, 30cm, and 60cm for root zone water status, FAO Penman-Monteith ET₀ firmware from co-located sensors, and FMIS delivery in the format the irrigation scheduling algorithm requires from day one.
ISOBUS, Variable Rate & Precision Application Electronics
TC-GEO · TC-SC AEF Certification. <25cm Section Control Boundary. Sub-200ms GNSS-to-Solenoid Latency. Individual Nozzle PWM. ISOBUS XML. FMIS Prescription.
Variable rate application ROI depends on section control activating at the right GPS position — not 3-5 seconds late, which applies the wrong rate to an 8-25 metre band at every zone boundary and affects 15-20% of field area in complex prescription maps. The total timing budget from GPS position update to nozzle flow response must stay below 200ms: ISOBUS position message latency from the Tractor ECU can reach 200ms alone, and at 8km/h forward speed, 1 second of total latency produces 2.2 metres of boundary location error. Ankh implements ISOBUS TC-GEO task controllers with section control boundary error below 25cm at 8km/h — validated across 14 commercial farm trials — with AEF TC-GEO certification engagement and documented conformance.
Livestock Management, Greenhouse & Farm Connectivity Electronics
Oestrus Detection. GPS Paddock Tracking. EID ISO 11784. Rumen Bolus. VPD. LoRaWAN 20km Rural Coverage. Iridium Satellite.
Livestock electronics must produce health and reproduction alerts at 3am while the farm manager is asleep — and a missed oestrus event costs a complete 21-day reproductive cycle. The firmware challenge is distinguishing a true oestrus event (3× baseline activity for 6-12 hours) from a false alarm generated by a social disturbance, while running continuous 25Hz accelerometer sampling alongside scheduled GNSS acquisition on a 2-3 year primary battery. Ankh designs livestock electronics from the specific use case power budget; for greenhouse and CEA, it designs multi-zone climate monitoring with NDIR CO2, VPD firmware, PAR/DLI, and hydroponic EC/pH/DO; and for farm connectivity, LoRaWAN gateway design for 15-20km rural coverage, LTE-M, and Iridium SBD for ultra-remote paddock monitoring.
Why Precision Agriculture Technology Companies Choose Ankh
Soil Sensing Calibrated for the Specific Soil, Not Generic Mineral Soil
The Topp equation was derived from four mineral soil textures with organic matter below 3%, introducing 4-8% VWC error in clay soils where surface water contributes to dielectric permittivity without contributing to plant-available water, and 6-10% error in high-organic-matter soils. Ankh develops soil-type-specific calibration equations for each installation soil using gravimetric sampling — oven drying at 105°C correlated with simultaneous TDR dielectric reading — so the irrigation controller receives volumetric water content for the specific soil and depth, not a generic approximation with a 50% safety margin that eliminates the water saving benefit.
ISOBUS Task Controller From AEF Test Suite Requirements, Not ISO Standard Alone
ISO 11783 protocol conformance does not cover the AEF interoperability tests that determine whether a TC actually works with John Deere, AGCO, CNH Industrial, and Claas tractor terminals in real field conditions. The AEF TC-GEO test suite includes position-based section control timing tests, GPS-triggered rate step change accuracy tests, and prescription map zone boundary transition tests that basic conformance testing does not cover. Ankh implements ISOBUS task controllers from AEF test suite requirements so the TC works with the farmer's existing fleet from day one, not after a firmware update campaign triggered by first-season field incompatibilities.
Agricultural Power Engineering From the Deployment Season, Not the Spec Sheet
A solar-powered soil node at 52°N must harvest enough energy in December and January — when the sun is 15° above the horizon at noon and days are 8 hours long — to sustain the sampling frequency that winter drainage management requires. A livestock ear tag in February must survive two weeks of cloud cover that reduces solar charging to near zero. Ankh designs agricultural power systems from worst-case seasonal energy analysis at the specific deployment latitude and crop calendar — so the device performs through winter, not just in the summer season when the procurement decision was made.
Agronomic Platform Integration That Works From Day One of Field Deployment
A precision agriculture platform expects soil moisture data as volumetric water content in m³/m³ with a depth label, temperature in °C, and sensor position in WGS84 decimal degrees — not raw ADC counts in a proprietary binary format requiring a custom parser before any agronomist can see the data. Ankh designs the agronomic data model, API payload format, and georeferencing architecture to match the specific FMIS platform the device must deliver to — so data appears in the agronomist's platform on the first day of field deployment, in the format the irrigation scheduling or variable rate recommendation algorithm expects, with no integration work from the platform vendor.
Multi-Depth Soil Moisture Monitoring Network — 1,400 Nodes, 34% Irrigation Reduction, 4.8yr Battery Life
LoRaWAN soil moisture and microclimate node for a precision irrigation platform serving commercial arable farmers — requiring soil-type-specific calibration at sub-3% VWC accuracy across 8 soil types validated by gravimetric sampling, FAO Penman-Monteith ET₀ calculation, 23km LoRaWAN rural connectivity from single gateways, and REST API delivering data in the irrigation scheduling format from day one.
TDR soil moisture at 10cm, 30cm, and 60cm with soil-type-specific calibration for clay, sandy loam, and silt loam; in-canopy temperature and humidity with aspirated radiation shield; Penman-Monteith ET₀ firmware from co-located net radiation, temperature, humidity, and wind sensors; tensiometer matric potential monitoring; LoRaWAN Class A with ADR across 23km of rural farmland; REST API delivering volumetric water content in the platform's required format from day one.
- 4.8-year primary battery life validated in thermal chamber at 5°C representing average soil sensor installation temperature at 52°N deployment latitude
- Sub-3% VWC accuracy across all 8 soil types validated by gravimetric soil sampling — including clay loam where generic Topp equation showed 7.2% overestimation
- 34% irrigation water reduction versus calendar-scheduled comparison plots across 180 commercial farms in first growing season
- 98.7% data completeness across 1,400 deployed nodes — LoRaWAN ADR managing link quality across diverse rural terrain from single gateway installations
ISOBUS TC-GEO Variable Rate Sprayer Controller — <25cm Boundary, 12% Input Saving, AEF Certified
Certified ISOBUS TC-GEO task controller for an agricultural technology company — requiring section control boundary error below 25cm at 8km/h with sub-180ms GPS-to-solenoid latency, individual nozzle PWM at 120Hz, ISOBUS XML task file import from FMIS platforms, and AEF TC-GEO certification engagement with documented conformance across all major tractor terminal variants.
ISOBUS TC-GEO task controller with boundary error below 25cm validated by geo-referenced application record analysis; individual nozzle PWM at 120Hz; 180ms total GNSS-to-solenoid latency; ISOBUS XML import from Climate FieldView and John Deere Operations Centre; ISO 11783-10 application record export; dual-antenna RTK GNSS at sub-2cm with machine heading; fouled nozzle detection at 3% pressure deviation; AEF TC-GEO certification engagement with documented conformance across John Deere, AGCO, CNH Industrial, and Claas.
- Section control boundary location error below 25cm at 8km/h validated across 14 commercial farm trials — 180ms total GNSS-to-solenoid latency achieved
- 12% average input saving versus non-section-controlled application across 14 commercial farm validation trials
- Savings exceeding 18% on irregular field shapes with complex headlands — GNSS-triggered automatic section deactivation at field boundaries
- AEF TC-GEO interoperability test suite engagement completed — documented conformance with John Deere, AGCO, CNH Industrial, and Claas terminal variants
Building smart agriculture or precision farming electronics? Let's grow something smarter.
Soil sensing calibrated for the specific clay mineralogy, organic matter content, and salinity of each installation soil — not generic Topp equation approximations with a 50% management safety margin. ISOBUS TC-GEO from AEF test suite requirements, not ISO 11783 conformance alone — so section control works with the farmer's John Deere, AGCO, CNH, and Claas fleet from day one. Full-stack delivery from soil physics calibration through GNSS RTK precision through FMIS platform API integration through multi-year solar-powered farm deployment at 52°N winter insolation minimum.
